Siemens 6SE3223-5DH50

The Siemens 6SE3223-5DH50 AC inverter drive, a MidiMaster Vector MDV1850/3 equipped with an integral Class A filter, is engineered for efficiency in various applications. Designed to operate on a 3-phase power supply, it supports a voltage range of 380-480V with a +/-10% tolerance and accommodates both 50 and 60Hz frequencies. With an impressive constant torque power rating of 18.5 kW, it allows for temporary overloads of 150% for 60 seconds and 200% for 3 seconds, making it suitable for demanding operational requirements. For variable torque applications, the power rating reaches 22 kW, expanding its versatility. The drive's dimensions are 800 mm in height, 275 mm in width, and 210 mm in depth, and it is rated IP20 (NEMA 1) for superior environmental protection, with a recommended operating temperature range of 0-40°C. This drive is widely available from numerous automation suppliers, offering flexibility in procurement and shipping options.
