Allen-Bradley 77135-230-03A

Part number 77135-230-03A pertains to the archived UFC 3-230-03A document, which has been superseded by UFC 3-230-01. This guideline, integral to the United States Department of Defense (DoD), outlines standards for the design and construction of water supply systems within military facilities. Although no longer in use, UFC 3-230-03A was comprehensive, detailing specifications for pipe sizes, flow rates, and pressure requirements while offering critical installation guidelines. It also outlined troubleshooting procedures for common issues such as leaks and pressure drops, allowing for effective system management. While user manuals and programming guidelines were not included, the document served as a vital reference for ensuring that military water supply systems met the required technical standards.
