Allen-Bradley 2198-KITCON-RP312

The 2198-KITCON-RP312 DC-bus conditioner module is an essential accessory for Kinetix 5700 servo drives, specifically engineered to minimize voltage stress on isolation components in inverter systems with extended cable lengths. This module effectively extends the DC-bus voltage to additional inverter clusters, accommodating systems with external DC-bus currents up to 104 A. It enables parallel connections with itself or another accessory module, supporting a total capacity of 208 A. Compatible with various DC-bus power sources, including regenerative and 8720MC-RPS supplies, it operates within a defined range of voltages and currents, ensuring optimal performance and safety. While detailed information regarding alarm codes, troubleshooting, and programming is generally available in the Kinetix 5700 Servo Drives User Manual, the module's installation and configuration processes are designed for ease of use, making it a valuable addition for enhancing the efficiency of your servo drive system.
