Allen-Bradley 2198-KITCON-CAPMOD2240

The 2198-KITCON-CAPMOD2240 parts kit is essential for the effective installation and connection of Kinetix 5700 capacitor and extension modules. This comprehensive kit features a stud/lug cover with wires, a lug cover bottom plate, hex nuts, spacers for M8 studs, and a 55 mm DC-bus link. It is specifically designed for setups where multiple capacitor and DC-bus conditioner modules are mounted in close proximity, ensuring proper electrical connectivity. The Kinetix 5700 capacitor module (2198-CAPMOD-2240) serves as a critical energy storage unit, extending the DC-bus voltage to additional inverter clusters with the capacity to handle external DC-bus currents up to 104 A, while allowing parallel configurations for up to 208 A. Similarly, the extension module (2198-CAPMOD-DCBUS-IO) is integral for extending DC-bus voltage in high-current applications, accommodating up to 200 A. Together, these components facilitate seamless integration and performance optimization within your system. The accompanying user manual provides comprehensive guidance on installation, configuration, and system bonding, ensuring users maximize the potential of their Kinetix 5700 series modules.
